Hillsboro Truck Beds
HB 2000 – Shown as 7’ x 8.5’
Standard Features
High Strength aluminum extruded floor with 3" Aluminum I-beam crossmembers with approximately 16" spacing
- Heavy duty extruded rubrail
- Extruded aluminum tie rail with stake pockets
- Adjustable height headache rack
- Louvered headache rack with LED lights
- 3" steel channel long sills, adjustable to 34", 38", or 42" frame
- Corrosion resistant
- Heavy Duty Treadbrite tailboard
- LED lights (6) stop, turn & tail and (4) back-up
- LED clearance and side marker lights
- Dual tag lights
- Automotive grade harness with plug in connections
- 30K Gooseneck ball plate with flush mount cover (2 5/16" 30K ball included)
- (1) Fuel filler kit
HB 2500 – Shown as 8’ x 8.5’
Standard Features
- 3 Year Warranty
- High Strength Aluminum Extruded Floor
- Heavy Duty Tread Brite Tailboard
- 3" Aluminum I-beam crossmembers with approximate 16" spacing
- Heavy Duty 6" tall extruded rubrail
- Heavy Duty adjustable height headache rack with square tube louvers
- 4"x2" tube steel long sills, adjustable to 34", 38", 42"
- Recessed aluminum castings for taillights and tag
- Tapered rear with step
- Tapered front on 96" wide dual wheel beds
- 3" Extruded tie rail w/ stake pockets
- Corrosion resistant
- LED lights (6) stop, turn & tail and (4) back-up
- LED clearance & side marker lights
- Sealed wiring harness with plug-in connections
- Lights and harness installed
- 30K Gooseneck ball plate with flush mount cover (2 5/16" 30K ball included)
- 18K Receiver Hitch with 2 1/2" tube
- 2" Adapter included
HB 3000
Standard Features
- 3 Year Warranty
- High Strength Aluminum Extruded Floor
- Heavy Duty Tread Brite tailboard
- 3" Aluminum I-beam crossmembers with approximate 16" spacing
- Heavy Duty 6" tall extruded rubrail
- Recessed stainless steel flip up tie downs
- Heavy Duty adjustable height headache rack with square tube louvers
- 4"x2" tube steel long sills, adjustable to 34", 38", 42"
- Fold down sides with slam latch
- Recesses aluminum castings for taillights and tag
- Tapered rear with step
- Tapered front on 96" wide dual wheel beds
- Corrosion resistant
- LED lights (6) stop, turn & tail and (4) back-up
- LED clearance & side marker lights
- Sealed wiring harness with plug-in connections
- Lights and harness installed
- 30K Gooseneck ball plate with flush mount cover (2 5/16" 30K ball included)
- 18K Receiver Hitch with 2 1/2" tube
- 2" Adapter Included
- Aluminum fuel door
HB 3500 – Shown as 8’ x 11.4’
Standard Features
- 3 Year Warranty
- Corrosion resistant
- Supersize Storage Compartments
- Toolboxes have weather-resistant EPDM closed-cell foam seal
- Toolboxes and skirting made of .125 thickness aluminum
- Latches are polished stainless steel, with key-locking 'T' handle
- B&W Compatible/Ready to accept optional Hillsboro B&W Conversion Kit
- 30K Gooseneck ball plate with flush mount cover (2 5/16" 30K ball included)
- 18K Receiver Hitch with 2 1/2" tube
- 2" Adapter Included
- High Strength Aluminum Extruded Floor
- Heavy Duty Tread Brite Tailboard
- 3" Aluminum I-beam crossmembers with approximate 16" spacing
- Heavy Duty 6" tall extruded rubrail
- Heavy Duty adjustable height headache rack with square tube louvers
- 4"x2" tube steel long sills, adjustable to 34", 38", 42"
- Recessed aluminum castings for taillights and tag
- Tapered rear with step
- Tapered front on 96" wide dual wheel beds
- 3" Extruded tie rail w/ stake pockets
- LED lights (6) stop, turn & tail and (4) back-up
- LED clearance & side marker lights
- Sealed wiring harness with plug-in connections
- Lights and harness installed
Popular Options & Accessories
Mud flaps with Hillsboro logo
HB 4000 – Shown as 7’ x 8.5’
Standard Features
- 3 Year Warranty
- Corrosion Resistant
- Supersize Storage Compartments
- Toolboxes have weather-reistant EPDM closed-cell foam seal
- Toolboxes and skirting make of .125 thickness aluminum
- Latches are polished stainless steel, with key-locking "T" handle
- B&W Compatible/Ready to accept optional Hillsboro B&W Conversion Kit
- 30K Gooseneck ball plate with flush mount cover (2 5/16" 30K ball included)
- 18K rated 2 1/2" receiver tube (2" adaoter included)
- High Strength Aluminum Extruded Floor
- Heavy Duty Tread Brite tailboard
- 3" Aluminum I-beam crossmembers with approximate 16" spacing
- Heavy Duty 6" tall extruded rubrail
- Recessed stainless steel flip up tie downs
- Heavy Duty adjustable height headache rack with square tube louvers
- 4" x 2" tube steel long sills, adjustable to 34", 38", or 42"
- 6" Fold down side rails
- Recessed aluminum castings for taillights and tag
- Tapered rear with step
- Tapered front on 96" wide dual wheel beds
- LED lights (6) stop, turn & tail and (4) back-up
- LED clearance & side marker lights
- Sealed wiring harness with plug-in connections
- Lights and harness installed
- Aluminum fuel door
INSTALLATION
Our truck bed installation consist of side plating the sub-frame of truck bed to the frame of truck (side plates are painted and undercoated), mud flaps front and rear of rear tires and bringing gas spout(s) out to the side rail of truck bed. Toolbox, bumper and electrical (trailer plug) installation also available
